Manufacturer Allied Moulded Products
Mfg Catalog # 9370-FR
Capital Electric Part # 5926

Features

1/2" deep base with side cube wiring capacity, fan/fixture screws for joist mounting

Specifications

  • Catalog #: 9370-FR
  • Width: 4 in.
  • Depth: 1-1/2 in.
  • Volume: 8 cu. in.
  • Round Ceiling Box
  • Carton Quantity: 24
  • Carton Weight: 6 lb.
  • UPC: 085339766001
  • UNSPSC: 39121316
  • Country of Origin: United States of America
  • Color: Beige/tan
  • Material: Fiberglass reinforced polyester BMC
  • Mounting: Bottom mount
  • Support Rating: 110 lbs fixture support and 70 lbs fan support

Additional Materials

  • Plated carbon steel fasteners
  • Nonmetallic pop-in cable clamp

Application

New and old work residential construction 2 HR fire resistive walls and ceilings (70 lbs. fan support and 110 lbs. fixture support)

Standards

ANSI / UL 514C: File No. E30594

Fire Classification

Fire Test of Building Construction Materials

  • ANSI / UL 263: File No. CEYY.R9379 (Category / File No.)
  • Note: Products must also be certified to: ANSI / UL 514C

Fire Resistance Classification in Wall Assemblies 2-Hours or less

  • Shall be separated by a horizontal distance of not less than 3 inches

Fire Resistance Classification in Floor-Ceiling Assemblies 2-Hours or Less

  • Distance between boxes in adjacent cavities may be reduced to 5 ½ inches
  • Note: For more details please refer to the UL fire resistive directory and Allied Moulded’s CEYY.9379 (Outlet boxes and fittings classified for fire resistance)

Overview

MDM UPC 08533976600
GTiN 00085339766001
Width 4 in
Size Depth=1 1/2", Dia=4"
Color Beige,Tan
Type 4" Dia. Round Fan Support Box For Use With Nonmetallic Sheathed Cable
Insulation Type Non-Conductive,Non-Metallic
Material Fiberglass
Applications New and old work residential construction 2 HR fire resistive walls and ceilings (70 lbs. fan support and 110 lbs. fixture support)
Mounting Type Bottom Mount
Depth 1-1/2 in
Standard UL 514 C
Family Brand Name Allied Moulded
Construction Compression Molded
Cable Entry Two 1/2" Knockouts With One Supplied Pop In Cable Clamp
