Thomas & Betts 2RA18 22 to 18 AWG 1.19 Inch Red Electrotinned Copper Nylon Insulated Butt Splice
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$114.90/c (100 ea)
ea
Adding...
Order in multiples of 100 (pack qty) Already a Customer? Log in to view your pricing
Manufacturer Thomas & Betts Co
Mfg Catalog # 2RA18
Capital Electric Part # 22034

Features

  • Nylon insulated splices meet or exceed the requirements of MIL-T-7928. These splices are color-coded according to wire size.

General

  • Finish: Electro -Tin Plated
  • Terminal Series: RA
  • Material: Copper
  • Wire Range: 22-18
  • Insulation Type: Insulated Nylon
  • Color: Red

Dimension Information

  • Maximum Insulation (inches): .115
  • Stock Thickness: .03
  • A (inches): 1.19
  • B (inches): .18

Specifications

  • Flammability Rating: UL 94 V-2
  • Voltage Rating: 600V
  • Temperature Rating: 105°C

Tooling

  • Application Tools: ERG4001, ERG4003, WT145C, WT112M
  • Recommended Tool: ERG4001

Packaging

  • Outer Package: 500
  • Package Width: 8.1
  • Package Type: Standard
  • Inner Package: 100
  • T&B Sold in UOM: Each
  • Alternate Package Qty: RAA21
  • Order Multiple: 100
  • T&B Weight Per UOM: 3.13 lbs. per 1000
  • Package Height: 10.2
  • Package Length: 12.3

Application Support

Certifications

Documents

Overview

UPC 78621080018
Product Description Nylon-Insulated Butt Splice, Length 1.19 Inches, Width .18 Inches, Maximum Insulation Diameter .115, Wire Range #22-#18 AWG, Color Red, Copper, Tin Plated
GTiN 05414363140528
Finish Electro-Tin Plated
Color Red
Voltage 600 Volt
Type Nylon Insulated Butt Splice
Insulation Type Insulated Nylon
Material Copper
Conductor Size 22-18 AWG
Temperature Rating 105 C
Family Brand Name Thomas & Betts
Contact Material Copper
Sub Brand Sta-Kon
